1. Product Description
All-in-one 4K UHD USB Video Conferencing Device
The VB342+ makes group video calls easier and more efficient, delivering excellent audio and video quality for businesses. The new VB342+ is also equipped with advanced features such as SmartFrame, SmartSpeaker, True WDR, and 120° horizontal FOV to upgrade your video conferencing experience.
AVer SmartFrame Captures Everyone
With AVer SmartFrame built in, the VB342+ automatically captures, adjusts camera zoom, pans, and focuses to capture everyone on screen in seconds.
SmartSpeaker identifies speakers instantly
SmartSpeaker’s highly sensitive tracking feature pinpoints voices anywhere in the room, cutting out background noise to magnify the speaker’s voice. Plus, SmartSpeaker’s 6-meter pickup and output range saves time moving voices closer to the microphone.
Absolute Clarity with True WDR
Wide Dynamic Range controls natural brightness and handles backlighting in high-contrast environments to deliver clear images. Hold your meetings anywhere and in any lighting with the VB342+.
Capture everyone in the room
The VB342+ covers the entire room with a 120° FOV lens that rotates 180° pan and 105° tilt for a wider view than ever before. No more worrying about where you sit.
Ability to Analyze Meeting Room Efficiency
The VB342+ provides API analytics so businesses and third-party software vendors can pull in attendance data to make more efficient use of meeting space.
2. Specifications
- Camera
-
- Sony Exmore sensor: Ultra crystal-clear image support up to 4K
- Frame rate: 4K 30fps; 1080p, 720p, 960 x 540, 848 x 480, 800 x 448, 640 x 480, 640 x 360, 424 x 240, 320 x 240, 320 x 180 at 60, 30, 15fps
- SmartFrame & SmartSpeaker: Automatic FOV adjustment (auto focus) to fit all participants and focus on the speaker
- 120° wide field of view
- True WDR up to 120 db: Superb back light compensation technology for optimizing light balance in high-contrast conditions
- Digital zoom rate up to 4X leveraging 4K sensor
- 3D denoise technology maintains clear and natural imaging in low light conditions
- Mirror, AE, white balance: Auto, manual override via PTZApp
- Minimum focus distance: 80 cm
- Analytics API: Enterprises and third-party software providers can obtain people-counting data for better understanding of meeting-space usage
- Audio
-
- Microphones: 2 unidirectional microphones supporting 6 m pickup
- 5Wx2 stereo full range speakers with professional bass port tuned for communication
- Volume up to 96 dB SPL at 1/2 meter
- Echo cancellation
- Noise suppression
- 3.5 mm Line-in (aux) cable connects BYOD smartphones or PCs as speakerphones
- Motorized Pan and Tilt Movement
-
- Pan: Total horizontal viewing area 180°
- Tilt: Total vertical viewing area 105°
- 10 camera presets (through remote control)
- Fast and quiet pan & tilt movement
- HDMI
-
- DisplayLink: Built-in USB 3.1 (Gen 1) to HDMI adapter
- 1080p HDMI output to TV
- Connectivity
-
- 12V/5A power adaptor
- Mini DIN6 for RS232 connection
- USB type C connector
- HDMI out connection (DisplayLink)
- Phone in (3.5 mm audio jack)
- Mic input
- Wireless connection with mobile devices**
- Video Format
-
- YUV, YUY2, M-JPEG
- USB
-
- 3.1 Gen 1, backward compatible USB 2.0
- UVC (USB Video Class) 1.1
- Control
-
- IR remote control
- VISCA/pelco P/pelco D via RS232
- UVC/UVA plug-and-play
- PTZApp
- Environmental Data
-
- Operation temperature: 0°C~40°C
- Operation humidity: 20%~80%
- Storage temperature: -20°C~60°C
- Storage humidity: 20%~80%
- Dimensions
-
- Package dimensions: 739 x 193 x 229 mm
- Package weight: 4.16 kg/9.3 lbs
- Camera: 650 x 100 x 109.5 mm/2.133 kg
- Remote control: 200 x 50 x 21 mm/0.09 kg
- Package Contents
-
- VB342+ unit
- Power cable 10 ft (3 m)
- USB 3.1 type-C to type-A Cable 6 ft (1.8 m)
- USB 3.1 type-A to type-C adapter
- Quick-start guide
- Wall-mount bracket and screws
- Warranty card
- Remote control
- Battery
- Optional Accessories
-
- Mini DIN6 to RS232 adapter
- TV mount and mounting screws
- 33 ft (10 m) expansion microphone
- 66 ft (20 m) expansion microphone
- 33 ft (10 m) USB 3.1 extension cable
- 66 ft (20 m) USB 3.1 extension cable
- 16 ft (5 m) USB 2.0 cable
- Hardware Specs
-
- 2.4 GHz Intel® Core™2 Duo processor
- 2 GB RAM or more
- USB 3.1 Gen1 port (supports 4K); USB 2.0 port (supports up to 1080p)
- Warranty
-
- Camera: 3 +2 years
- Accessories: 1 year
- Compatible Applicati
-
- Zoom, Microsoft® Teams, Skype for Business, Skype, Google Hangouts, Intel® Unite™, RingCentral, BlueJeans, V-Cube, LiveOn, CyberLink U Meeting®, TrueConf, Adobe Connect, Cisco WebEx®, Fuze, GoToMeeting™, Microsoft® Lync™, Vidyo, vMix, WebRTC, Wirecast, XSplit
